HELLER ACH1 User Manual

Indoor Unit
Indoor Unit
Outdoor Unit
Installation board
Middle frame
Indication light and signal receiver
Front panel
Horizontal airflow direction vane
Vertical airflow direction vane(inner)
Air filter
Drain pipe
Pipe and Drain pipe
Cut-off valve
Outlet cover
Note:
Figure 1 is for illustration only.
Please refer to product gift box
for actual products appearance.
11
12
Outdoor Unit
Parts Description
2
1
Fig.1
Pipe protection ring

HELLER ACH1 Specifications

General

Brand	HELLER
Model	ACH1
Category	Air Conditioner
Language	English
