Hendi 970294 - Page 10

10
EN
Part list (Item no: 970294)
Part no. Part name Quantity Part no. Part name Quantity
1 Encloser 1 20 Slide mulch 1
2 Active clapboard 1 21 Power line 1
3 Food salver 1 22 Slide axle 1
4 Blade guard disc 1 23 Knob with scale 1
5 Blade 1 24 Spring gasket 1
6 Blade guarding ring 1 25 Cam 1
7 Tray bracket 1 26 Cam osculant staff 1
8 Food and fixed-arm 1 27 Slider 1
9 Fixed-arm bushing 1 28 Slide axle briquetting 2
10 Fixed-arm handle 1 29 Spring of towing bracket axle 2
11 Plastic granule 1 30 Towing bracket axle 1
12 Motor 1 31 Quadrate axis 1
13 Motor briquetting 1 32 Towing bracket 1
14 Fixed-arm pin Ø12×185 1 33 M8×35Hexagonal screw 1
15 Blade guard bolts 1 34 Ball bearing607 1
16 Ball bearing 6202 2 35 Towing bracket cover knob 1
17 Blade belt wheel Ø66 1 36 Relay 1
18 Pin of belt wheel 1 37 Capacitor 1
19 BeltSV.330 2 38 Capacitor retainer 1
