Hendi 970294 - Technical Specifications

11
EN
Part no. Part name Quantity Part no. Part name Quantity
39 Button mulch 1 65 Fixed-arm handle bolt 1
40 Button switch 1 66 Finger baffle bolt 2
41 Motherboard 1 67 Finger baffle nut 2
42 Meatscraper 1 68 Bracket knob bolt 1
43 Sharpener mulch 1 69 Undee spring gascket 1
44 Sharpener base of subassembly 1 70 Motor impacted bolt 1
45 Sharpener base of assembled 1 71 Meat scraping shim 2
46 Button of sharpener 2 72 Meat scraper bolt 2
47 Fine grinding wheel Ø45 1 73 Capacitor fixation clamp bolt 1
48 Crude grinding wheel Ø45 1 74 Tray bearing cover A 1
49 Pin of rubbing stone 2 75 Meat board bracket 1
50 Spring 2 76 Tray bearing cover B 1
51 Pin of sharpener bracket 1 77 Cross recessed countersunk head
M6×12
2
52 Sharpener tighten knob 1 78 Slide axle briquetting bolt 4
53 Active clapboard mandril 1 79 Quadrate axis locking screw 2
54 Rubber foot 4 80 Slider adjust bolt 1
55 Pin of blade guarding ring 2 81 Magnet 1
56 Meat blocking board 1 82 Magnet switch 1
57 Slide axle bracket 2 83 Aluminium block 1
58 Small belt wheel of motor 1 84 Microswitch 1
59 Slide driver 1 85 Stainless steel lock 1
60 Belt wheel setting 1 86 Limited block 1
61 Sharpener setting 1 87 Stainless steel bar 1
62 Ø15 Spring gasket for bearing 1 88 Set screw for tray bracket 1
63 Ø15 Spring gasket for bearing 1 89 Oil seal 1
64 Blade guard disc square-head nut 1
Technical specifications
Article number: 970294
AC power supply: 220-240V~ / 50 Hz
Power: 280W
Blade diameter: 220mm
Waterproof protection class: IP33
Protecion class: Class I
Noise level: < 70 dB (A)
