User manual // Integra Plus // Compact flash unit
46 HENSEL-VISIT GmbH & Co. KG
Before reinstallation of the new battery, the polarity must
be observed. The positive pole should be pointed toward
the Power Down 21a button.
Technical data*
Transmitter
Type:
Code No.:
Strobe Wizard
Plus
3950
freemask
3955
Sync socket:
2,5 mm jack plug, Mono
Sync. voltage /
Sync. current:
3V /
< 1mA for 5 µs
Channels:
3, selected by sliding switch
Shutter time for
synchronization:
1/250 s
Dimensions in cm
(width x length x height):
5,5 x 6,3 x 4,8
Weight (with battery):
53 g
Type of battery:
28L / 6V, 1 pc.
Battery life:
1 - 2 years
Range:
> 40 m (131 feet) free visibility
Frequency:
433,92 MHz
*: This product conforms to the radio standards ETSI EN300220 and FCC15.231
freemask
Channel selection:
An additional function is available, when selecting the
channel (click flash energy regulator 13 once): the
channels F1, F2, and F3 can be set additionally, besides
the channels C1, C2, and C3.
When using the compact flash units for normal lighting of
a set with the channels C1, C2, and C3, you can trigger
the flash via radio remote, adjust the modelling light, and
set the flash power via radio remote control, just like you
have been used to so far.
The freemask application for the second group of flash
units does not allow you to switch the modelling light or
the flash power via radio remote. You can only use the
channels F1, F2, and F3 to differentiate between up to
three different, separate work stations.
21a
freemask
transmitter
(Code no. 3955)
