6.9 Adjustment of armrest
Adjusting the armrest is something
you can do yourself and is both simple
to do and doesn’t require tools.
e armrest height can be adjusted
seamlessly by loosening the wheel C
and then raising or lowering it to suit
the user. Once the desired position is
found, the steering wheel locks again.
For increased ease of use, the armrest
can be folded all the way down, which
allows entry to the seat from the side.
In addition to height adjustments,
the armrests can also be modified to
extend the width of the chair - up to
5 cm ( 10 cm in total) on each side. For
adjustment, loosen ratchet bracket D
and pull armrest to desired position.
en fasten the ratchet bracket. Ensure
that the ratchet mount D always points
forward (parallel to the chair direction)
after adjustment.
NB! Always raise the armrests from
the folded position before they are
adjusted sideways so that they can
move freely.
ARMREST
Loosen the wheel
to adjust width
C
CHAIR WIDTH
Loosen the wheel
to adjust width
D
