Page 10 For technical questions, please call 1-888-866-5797. Item 57285
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Phillips Screw + Flat Washer 2
2 Rubber Feet 4
3 Base Cover 1
4 Circuit Board 1
5 Phillips Tapping Screw 2
6 Circuit Board Cover 1
7 Hex Bolt +Spring Washer 2
8 Screw + Flat Washer+Spring Washer 2
9 Capacitor 1
10 Base 1
11 Wire Clamp Plate 1
12 Phillips Screw 4
13 Lead Wire Clamp 1
14 Lead Wire With Plug 1
15 LED Light 1
16 Flat Washer 1
17 Hex Thin Nut-Fine Tread 1
18 Hex Flange Nut 4
19 Left Wheel Cover 1
20 Nut 1
21 Phillips Screw 1
22 Wiring Fixing Button 1
23 Hex Flange Nut 1
24 Potentiometer 1
25 Switch Plate 1
26 Knob Washer 1
27 Variable Speed Knob 1
28 Switch Guard Board 1
29 Phillips Screw 2
30 Self-Locking Switch 1
31 Flange 4
32 Grinding Wheel 1
33 Nut 1
34 Right Wheel Cover 1
35 Grinding Wheel 1
36 Wheel Cover Knob 6
37 Outer Locking Washer 2
Part Description Qty
38 Lead Wire Bushing 3
39 Left Inner Wheel Guard 1
40 Phillips Screw + Flat Washer 4
41 Left End Cover 1
42 Wave Type Spring Washer 1
43 Deep Groove Ball Bearing 2
44 Stator 1
45 Rotor 1
46 Right End Cover 1
47 Optical Coupler 1
48 Phillips Screw 2
49 Feedback Board 1
50 Hex Socket Set Screw 1
51 Right Guard Cover 1
52 Hex Flange Nut 8
53 Eye Shield Locking Knob 2
54 Flat Washer 4
55 Eye Shield Support 2
56 Eye Shield 2
57 Eye Shield Block Plate 2
58 Phillips Screw 4
59 Hex Bolt+Spring Washer+Flat Washer 4
60 Right Spark Guard 1
61 Neck Screw 2
62 Right Inner Wheel Guard 1
63 Right Work Rest Support 1
64 Right Work Rest 1
65 Locking Knob 2
66 Phillips Screw + Spring Washer 6
67 Left Spark Guard 1
68 Left Work Rest Support 1
69 Left Work Rest 1
70 Flat Washer 6
71 Spring Washer 6
72 Hex Bolt 4
73 Flat Washer 4
74 Locking Washer 1
To Next Page
