Hercules HE64 - Parts List and Diagram

Page 12 For technical questions, please call 1-888-866-5797. Item 56932
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Tapping Screw 4
2 Deck 1
3 Shaft Cover 1
4 Collet Nut 1
5 Collet 1
6 Spindle 1
7 Fan 1
8 Shaft Circlip 1
9 Hole Circlip 1
10 Ball Bearing 1
11 Rubber Ring 1
12 Ball Bearing 1
13 Circlip 1
14 Seal Ring 1
15 Bearing Retainer 1
16 Thread Forming Screw 2
17 O Ring 4
18 Shaft Connector 2
19 Middle Cover 1
20 Circlip 1
21 Ball Bearing 1
22 Rubber Ring 1
23 Bearing Retainer 1
24 Screw 2
25 Rotor 1
Part Description Qty
26 Dust Cover 1
27 Ball Bearing 1
28 Bearing Holder 1
29 Tapping Screw 2
30 Clamp 2
31 Stator 1
32 Fan Baffle 1
33 Switch Actuator 1
34 Spring 1
35 Front Housing 1
36 Switch Button 1
37 Carbon Brush 2
38 Tapping Screw 4
39 Brush Holder 2
40 Spiral Spring 2
41 Switch 1
42 Tapping Screw 2
43 Cord Anchorage 1
44 Cord Guard 1
45 Rear Housing 1
46 Tapping Screw 1
47 Power Cord & Plug 1
48 Large Wrench 1
49 Small Wrench 1
