4.2 Clamp bow
Installation:
1. Let the installation of the seat and adjustment
of it be shown to you during the delivery.
2. Open the setscrews on the left and right
and pull the bracket to the rear.
3. Adjust the back rest of the car's seat to the
required angle, taking advantage of the space
created to the car's back pad. Now push the
clamp on both sides backwards in the direc-
tion of the backrest, until it sinks into the gap
of the car seat and seat upholstery and
remains firm.
4. Push the car seat against the backrest of the
vehicle until it rests flat.
5. Now close the two setscrews left and right.
6. Whether the offset of the bow must be
directed upwards or downwards depends on
the construction of the respective passenger
car seats.
Removal Note:
1. Pull the car seat including the clamp out of
the gap of the car seat.
Herni
IV. Using the optional accessories
• Page 11 •
