Herni
TABLE OF CONTENTS
I. General information Seite
1.1 Introduction 2
1.2 Purpose and indication 2
1.3 Relevant information 3
1.4 Declaration of conformity 3
1.5 Warranty 3
1.6 Service and repair 3
1.7 Practical instructions 3
1.8 Installation in the car 4
1.9 Adjusting the head rest 4
1.10 Using the 3-point-harness 5
II. Safety instructions
2.1 Safety instructions 7
III. Handling and functions of the basic seat
3.1 Adjusting the internal 5-point-belt 8
3.2 Using the separate adjusters 8
3.3 Adusting the height of the back rest 9
3.4 Adjusting the angle of the back 9
IV. Using the optional accessories
4.1 ISOFIX-adapter 10
4.2 Clamp bow 11
4.3 Security tray 12
4.4 Lateral supports 12
4.5 Abduction block 13
4.6 Angular adjustment 13
4.7 Foot rest / foot roll 14
4.8 Swivel 14
4.9 Protection mat 15
4.10 Belts to connect the chest straps 15
V. Guarantee 16
VI. Labeling 16
VII. Maintenance & product care
7.1 Pull off the cover 17
VIII. Technical characteristics 18
• Page 1 •
