SAFETY FIRST:
Prior to set-up or maintenance, ensure that the unit is disconnected from the power
supply.
Ensure that the unit remains in a dry area and that it is not accessible to people unfamiliar
with its operation.
The unit is intended for switching the electrical load associated with HID (High Intensity
Discharge) lighting with a total load not exceeding either 8 x 600W or 4 x 1000W.
The unit has two power cords, each capable of carrying up to 13 A. The power cord on
the left hand side is the ‘master’ power cord and also supplies power to the timer and
contactor. The left hand side should be plugged in for the unit to function.
Check the input current required by your individual HPS lighting systems, the total current
required by all lighting systems on either side of the unit should not exceed 13A. For
safety reasons, any load applied to the unit should be evenly distributed across both sides.
Do not plug the unit into extensions or adaptors as the current will be too high for these
and may create a risk of fire.
Upon switching the unit off, leave at least 5 minutes before unplugging it to allow any
connected appliances to safely discharge.
INSTALLATION
To mount the unit on a wall use the installed brackets as shown below.
Four brackets are pre-installed on the unit. Fit a fixing through the hole in the bracket
and fix to the mounting surface.
