Model# 8896231
1. Recoil starter knob
2. Manual switch of gas inlet
3. Gas inlet
4. Engine
5. Oil drain plug
6. Oilllercap
7. Baery(notequiped)
8. Engine switch
9. AC receptacle
10. DC circuit breaker
11. DC 12v receptacle
12. Ground(Earth)terminal
13. AC breaker
14. Fuel tank
15. Fuelmeterassy
16. Hz/HNdisplay
17. Handlebolt(notequiped)
18. Fuel tank cap
19. Fuel stop cock
20. Carburetorassy
21. Choke lever
22. Airlter
77
8896231 • 8896322 • 8896324
Model # 8896322
1. Engine
2. Oil drain plug
3. Oilllercap
4. Manual switch for gas inlet
5. Gas inlet
6. ATSOutput(notequiped)
7. Ground(Earth)terminal
8. DC12V Receptacle
9. DC circuit Breaker
10. ATSConnector(notequiped)
11. Hz/H/VDisplay
12. AC Outlet X2
13. AC Breaker
14. Engine switch
15. Smallfrontcover(notequiped)
16. Bigfrontcover(notequiped)
17. Boltforfrontcover(notequiped)
18. Fan(notequiped)
19. LPG/CNG switch
20. Airlter
21. Axlewithbrake(notequiped)
22. Choke lever
23. Baery
24. OilAlarm
25.Pilotlamp
26. Recoil starter
27. ATScontroller(notequiped)
28. ATSmodelswitch(notequiped)
29. ATSstop/startswitch(notequiped)
30. Citypowerindicator(notequiped)
31. Generatorindicator(notequiped)
32. Outputindicator(notequiped)
33. Loadsterminal(notequiped)
34. Generatorterminal(notequiped)
35. Citypowerterminal(notequiped)
36. ATSConnector(notequiped)
37. Groundingterminal(notequiped)
38. Fuse(notequiped)
39. Fuel tank
40. Fuel tank cap
41. Fuelmeterassy
42. Fuel cock
