HERON 8896231 - Illustrated Parts Identification; Parts for Model 8896324

88
Model: 8896324
1. Engine
2. Oil drain plug
3. Oilllercap
4. Baery
5. ATS Output
6. Hz/H/V Calculagraph
7. AC receptacle
8. Ground(Earth)terminal
9. DC12V Receptacle
10. DC circuit Breaker
11. AC Breaker
12. Fuel tank
13. Fuel tank cap
14. Fuel level gauge
15. Engine switch
16. Fuel cock
17. Choke lever
18. Airlter
19. Recoil starter knob
20. ATS Connector
21. Volt Meter
22. ATS controller
23. ATSmodelswitch
24. ATS stop/start switch
25. Citypowerindicator
26. Generator indicator
27. Output indicator
28. Loadsterminal
29. Generatorterminal
30. Citypowerterminal
31. ATS Connector
32. Groundingterminal
33. Fuse
99
8896231 • 8896322 • 8896324
Assembly Model 8896231
ToolsRequired
1. Adjustable wrench
2. Philips screwdriver
Instrucons:Verylileassemblyisrequiredforthismodel
Note:Allhardwarespeciedisprovidedwiththeassemblykit
1. Removethegeneratorbodyandpartsboxfromthepackaging.
2. Fillthegeneratorwithoil.(10W-30oil,600ml)
