Operaon of your new generator
ForPetrolOperaon:
1. Fillthepetroltank(91octaneunleadedpetrol)
 8896231:15l,8896322:25l,8896324:28l
2. Ensurethepetrolstopcockisintheonposion(Seebelow)andthegasstopcockisinthe“OFFposion
ForGasoperaon
1. Connectagassupply(LPGorCNG)totheinputnipplelocatedonthegeneratorfrontpanel.
 Note:LPGPressure:2.8-6.0Kpa
  CNGPressure:2.0-4.2Kpa
2. Ensurethegasstopcockisinthe“ON”posionandthepetrolstopcockisinthe“OFF”posion.
3. Usingtheselectorswitchonthesideofthecarburetorsetthecarbtothecorrectfuel.
Seediagrambelow.
4. Ensure the gas is turned on at the source.
Cauon:
Ensure that the regulator provides gas to the generator at the pressures detailed in the
specicaons for the model being assembled.
Ensure that all connecons are ght and all equipment is within its test dates and is in good
condion and suitable for its intended purpose.
Fuel Stopcock
Gas Stopcock
TypicalInputNipple
1313
8896231 • 8896322 • 8896324
ForbothPetrolandGasOperaons
For cold start
1. Move the choke lever to the “CLOSED” posion.
2. Set the circuit breaker to the “OFF” posion.
3. Set the Engine switch to the “ON” posion.
Manual Start
4. Pull the rip cord to start the engine.
Electric Start
4. Push the engine switch to the “START” posion, once the engine is running release the switch.
5. Once the engine is running smoothly move the choke to the “OPEN” posion.
6. Connect electrical devices to the generator, ensuring that their combined power requirements is less
than or equal to the capacity of the generator (e.g. do not overload the generator).
7. Set the circuit breaker to the “ON” posion.
Shung Down the Generator
1. Set the circuit breaker to the “OFF” posion.
2. Set the engine switch to the “OFF” posion.
3. Close all the fuel stopcocks.
4. Ensure that all gas sources are turned o at their source.
5. Allow the generator to cool prior to moving.
Warning:
* The engine and muer will be very hot aer the engine has been run.
* Avoid touching the engine and muer while they are sll hot with any part of your
body or clothing during inspecon or repair.
* Fuel is highly ammable and poisonous.
* Be careful during refueling.
* Do not ll above the top of the fuel strainer or it may overow when the fuel heats up
later and expands.
* Wipe up any spilled fuel immediately.
* Aer refueling, make sure the tank cap is ghtened securely.
Circuit Breaker
