VTPH-2 Vacuum Tube Phono Preamplifier Owners Manual
Please read the Owner’s Manual Completely BEFORE operating the unit
5
IMPORTANT! (U.K. only)
This unit is supplied in the U.K. with mains lead fitted with a moulded 13
amp plug. If, for any reason, it is necessary to remove the plug, please remove
the fuse holder and dispose of the plug safely, out of reach of children.
It must not be plugged into a mains outlet.
The wires in the mains lead supplied with this appliance are coloured in ac-
cordance with the following code:
Green and yellow..............Earth
Blue................................Neutral
Brown.................................Live
WARNING - This appliance MUST be earthed
As the colours of the wires of the mains lead of this appliance may not cor-
respond with the coloured markings identifying the terminals in the plug,
proceed as follows:
The wire which is coloured green-and-yellow must be connected to the
terminal in the plug which is marked with the letter E or coloured green or
green-and-yellow, or by the earth symbol :
The wire which is coloured brown must be connected to the terminal
which is marked with the letter L or coloured red.
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black.
If connecting to a BS1363 plug, a 13 amp fuse must be used.
WARNING:
ANY MODIFICATIONS TO THIS PRODUCT NOT EXPRESSLY
APPROVED BY HERRON AUDIO WHO IS THE PARTY RESPON-
SIBLE FOR STANDARDS COMPLIANCE COULD VOID THE USER'S
AUTHORITY TO OPERATE THIS EQUIPMENT.
