7HRD Diesel Generator 498-1052
Specifi cation
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
A A B B
C C D D
E E
F F
C
Material Finish
Title
Drg No.
For insert & fabrication specifications refer to PD999-001
12.05.14
HRD270T1 General Arrangement
WG-HRD270T1
A
R.W
12.05.14
Item
Description
Item
Pt No.
Item
Material
Sht
No.
Weight (kg)
3D Views
2/2
3D views are for illustration only.
Tow Bar
Oil Drain Point
Hot Air Outlet
4 x Bolt-down Holes
for M16 Fixings
Fully Bunded Base
containing 150L Fuel Tank
Cable Outlet for
Terminal Output,
Earth Cable &
Remote Wiring
Bolt-on End Panel
with access to Silencer
Lockable Door with
access to Battery Isolator
Main Door Stay
External Fuel
Connections
Forklift Pods
Lockable Main Service Door
with access to
Fuel Filler Neck,
Document Holder &
Internal/External Fuel Selector
Output Sockets
Lockable Door
over DSE Controller
& 1ph/3ph Switch
Access Cover to
Terminal Outputs
Emergency Stop
Cool Air Inlet
Bolt-on End Panel
with access for
Battery Removal
Lifting Beam
Access
Radiator
Access
Hot Air
Outlet
Exhaust Outlet
with Rain Cap
