HGI Generators HRD270T1 - General Arrangement HRD270 T1

Harrington Generators International
6 HRD Diesel Generator 498-1052
Specifi cation
A
B-B
C-C
D-D
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
A A B B
C C D D
E E
F F
C
Material Finish
Title
Drg No.
For insert & fabrication specifications refer to PD999-001
12.05.14
HRD270T1 General Arrangement
WG-HRD270T1
A
R.W
12.05.14
Item
Description
Item
Pt No.
Item
Material
Sht
No.
Weight (kg)
BB
CC
D D
A
3D views are for illustration only.
1/2
900 kg unfueled 1030 kg fueled (150L)
General Arrangement
Item Part No.
Description
No. O
1 015-702 Lombardini KDI2504M/G15 1 2 LMED0048967900-S Connector Kit for Lombardini KDI 1 3 020-658-DER
Mecc Alte ECP28-VL/4 Alternator 1
4 040-779-028 T500X Alternator X-member 1 5
040-779-A
T500X Canopy
1
6 070-470
AV Mount Captive, M10, 50 shore
2
7 160-136-A T500X Foam Kit 1 8 160-136-B
T500X Additonal Foam Kit, Lombardini
1
9 610-528
T500X KDI2504M Engine Install Kit
1
10 620-509
T500X Exhaust Kit, Lombardini
1
11
630-504
T500X Battery Kit 12V
1
12 640-511-LOM T500X Fuel Kit Lombardini 1 13 650-506
T500 Oil Drain Kit, Lombardini
1
14
660-504 T500X Hardware Kit
1
15 660-505-A T500X Foam Retainer Kit 1 16 660-505-B
T500X Additional Foam Retainer Kit, Lombardini
1
17 690-562
HRD270T1 1ph/3ph Switched
1
18 TB334
T500X DC Engine Wiring Box, Lombardini
1
15
7
8
18
5
14
