3
1 2 3 4
2. Module Appearance and Interface
Pin interface definition: (2mm pitchpin header connector isrecommended for the interface)
Pin
Name
Remark
1
VCC
Power supply
5V power
supply
2
GND
Touchdown
3
URX
TTL serial
port receive
4
UTX
TTL serial
transmission
