Hi-Link HLK-LD1125H-24G - Module Performance; Debug Wiring and Configuration; Debug Wiring

4
23.5G-24.5GHz
Frequency
Typical value
valueTypical
value值
Parameter
\
JNJJJJJK
ameter
Antenna half power
angle
+/-22° (horizontal/vertical)
Data Format
Modulation
FMCW
Detection distance
4m meditate, 8m exercise
Serial ASCII
output
3. Module Performance
Scope Hanging height 3m, static human detection coverage radius>2m
Power
supply电
3.3-5V
Current
80mA
Output serial
3.3V
Detection cycle
4. Debug wiring
HLK-LD1125H-24G uses the serial port to output the test results in string format, so in the
testing, you can do a quick test evaluation on the serial port assistant firstly.
adaptive
