HLK-LD2410B
manual
5.4 Installation method and sensing range
ceiling
radar
high2.6~3rice
Figure 7 Schematic diagram of ceiling installation
(distance unit: meter, angle unit: degree)
Figure 8 Schematic diagram of the detection range (the height of the ceiling is 3 meters)
Page 10 of 20
