6
MACHINE DETAILS
The image below shows parts and accessories included with your All-U-Need machine:
SPEED CHART
The motor installed in the All-U-Need
is variable speed, delivering speeds of
800 rpm - 3,400 rpm. Use this speed
chart as a guide so you can work at
the speed you desire. These values
are approximate. Actual speeds may
vary.
3,400 rpm 800 rpm
1,800 rpm
2,300 rpm
1,200 rpm2,900 rpm
1
2
3
4
6
5
7
8
9
10 11
1. Water cup with black
water tube and valve
2. Silver arbor with black
knob and washer
3. Black spray shield
4. All-U-Need base unit (1/4
hp variable speed motor)
5. Clear drain tube
6. Water cup with cup holder
7. 3/32" Allen wrench
(included with instruction
manual)
8. 360# diamond disc with
acrylic backing plate
9. 600# diamond disc
10. 1,200# diamond disc
11. 3,000# diamond disc
12. Tech-11 polishing pad
with 14,000# diamond paste
syringe
13. Acrylic backing plate - to
be used with Tech-11 pad
14. Disc bushing - inserts
into backing plate arbor hole
12
14
13
