Hiddenbed Vertical hidden bed - Mechanism and Hardware Kits

3
MECHANISM KIT
Link Pivot
2 Sets
Bushing & Bolt
2 Sets
Lock
2 Pcs.
Note: Bed legs (L+R), are installed on bed sides.
HARDWARE KIT
Note: Assembly of Hiddenbed requires 2 people.
BOLTS 1/4”-20 1-1/4’’ FH
16 Pcs.
NUTS 1/4’’-20
16 Pcs.
SCREW - #8 5/8” PH
6 Pcs.
CAM LOCK PINS
66 Pcs.
SCREW - #8 3/4” PH
32 Pcs.
POWER BAR (located in desk box)
1 Pc.
VELCRO
FELT PADS & COLORED TABS
