8
FINAL ASSEMBLY
7 Insert “Link Pivot” bushings in ø12 mm holes on the desk sides and attach plates loosely
with 5 mm bolts.
Insert same bushings in the holes on the bed sides and carefully flip bed assembly over
desk. NOTE: Assembling of HiddenBed requires 2 people!
8 Tighten all 5 mm bolts using 4 mm Allen key.
9 Push bed-desk assembly inside bed body and attach it to the mechanism with bushing
and 12mm bolts. To align bolts and mechanism holes, tilt bed legs for few inches and tilt
whole bed up. NOTE: Desk is hanging 1/4 inch above floor.
