Basic components
Choke knob for pull type
To supply the engine with the rich fuel mixture required start, pull out this knob.
Manual starter handle
To start the engine, rst gently pull the handle out until resistance is felt. From that position, then
pull the handle straight out quickly to crank the engine.
Steering friction adjuster
A friction device provides adjustable resistance to the steering mechanism, and can be set
according to operator preference. An adjusting screw or bolt is located on the swivel bracket.
To increase resistance, turn the adjuster clockwise.
To decrease resistance, turn the adjuster counterclockwise
10
