Setup
Quick Start
Installation Guide
The illustrations below describe the various controls. Refer to
the illustration that matches your amplier.
The gain control purpose is to match
the output of your source signal to the
amplier. Refer to the section B below for
detailed instructions.
This switch will set the amplier to have
a full frequency output or to lter out high
or low frequencies. The NA1-400.2 offers
either a bandpass or a high pass lter.
The Low Pass Filter will cut off the
frequencies above the setting. The High
Pass Filter will cut off the frequencies
below the setting.
The Boost Switch will increase the signal
12dB at 45Hz. Be aware this setting can
cause distortion if the gain is not set
properly.
The Subsonic Filter will cut off the
frequencies below the setting. If using
with a subwoofer the settin should be kept
between 15-25Hz.
1. If possible, with the source unit off, conrm that the primary volume control is
turned down (counter clockwise).
2. Turn on the source unit (CD, or MP3 player). Re-conrm that the volume is
turned down. Make sure the source unit controls; balance, fader, bass and
treble are all set to center or “0” adjustment. Make sure that the green LED on
the end of the amplier is illuminated.
3. Play a clean musical selection of which you are very familiar. CD is preferred.
Do not use radio signals for level setting. Hit play and start turning the volume
of the source unit up.
4. Stop increasing the source unit volume when you reach 3/4 (about 75%) or until
you hear speakers begin to slightly start producing distortion.
5. Increase the amplier gain (clockwise) until distortion is heard, then back
the level down (counter clockwise) until the distortion is eliminated. Small
adjustments may need to be made to balance the levels of multiple ampliers.
Settings
A
This is a critical step to insure your amplier
is properly adjusted to match the signal
output level of your source unit.
THIS IS NOT A VOLUME CONTROL!
Level Setting
B
WARRANTY
Maxxsonics USA Inc. warrants this product, to the original consumer purchaser, to be free from
defects in material and workmanship for a period of one (1) year from the date of purchase.
Maxxsonics USA Inc. will, at it’s discretion, repair or replace defective products during the warranty
period. Components that prove to be defective in materials and workmanship under proper installation
and use must be returned to the original authorized Maxxsonics USA Inc. retailer from where it was
purchased. A photocopy of the original receipt must accompany the product being returned. The
costs associated with removal, re-installation and freight are not the responsibility of Maxxsonics
USA Inc. This warranty is limited to defective parts and specically excludes any incidental or
consequential damages connected therewith. To view the full warranty, please visit the website.
The information contained within this document is intended to offer some basic guidelines
for a few of the most common installations. More complex audio systems should be
installed by a competent professional. Additional installation information available at
www.maxxsonics.com
Hifonics products are designed and engineered in the USA by
www.maxxsonics.com
Congratulations on your choice of a Hifonics amplier.
This “Quick Start Installation” guide is meant to help you
“hook up” and play music. For more detailed information,
on system setting, speaker and subwoofer conguration
and full specications by model visit the website,
http://hifonics.com/manuals.html
HF TPS-A QSG 01 - rev1
TPS-A500.2
TPS-A 350.4
T P S - A 5 0 0 .1
TPS-A600.5
