HIGH ONE 10S49 E W701T - Description of the Appliance; Installation

5
EN
Using the appliance
B
4
EN
Preview of the appliance
A
Description of the appliance
General appearance
1
Worktop
2
Upper basket with racks
3
Upper spray arm
4
Lower basket
5
Lower spray arm
6
Filters
7
Rating plate
8
Control panel
9
Detergent and rinse-aid dispenser
10
Cutlery basket
11
Salt dispenser
12
Upper basket track latch
13
Mini Active Drying Unit:
This system provides better drying performance for your dishes.
Technical specifications
Capacity 10 place settings
Dimensions Height
Width
Depth
850 (mm)
448 (mm)
598 (mm)
Net weight 38,300 kg
Operating voltage / frequency 220-240V / 50 Hz
Total current (A) 10(A)
Total power (W) 1900(W)
Water supply pressure
Maximum: 1 (Mpa)
Minimum: 0.03 (Mpa)
Machine positioning
• When positioning the machine, place it in an area where dishes can be easily loaded and
unloaded. Do not put the machine in an area where the ambient temperature falls below 0°C.
• Read all warnings located on the packaging before removing the packaging and positioning
the machine.
• Place the machine close to a water tap and drain. Take into consideration that the connections
will not be altered once the machine is in position.
• Do not hold the machine by its door or panel.
• Leave an adequate distance around the machine to allow ease of movement when cleaning.
WARNING
Ensure the water inlet and outlet hoses are not squeezed
or trapped and that the machine does not stand on the
electrical cable while positioning.
• Adjust the feet so the machine is level and balanced. The machine should be placed on
flat ground otherwise it will be unstable and the door of the machine will not close properly.
Water connection
We recommend fitting a filter to your water inlet supply in order to prevent damage to your
machine due to contamination (sand, rust, etc.) from indoor plumbing. This will also help
prevent yellowing and deposit formation after washing.
Installation
