DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
3 of 9
Part 1: Lock+ & Lock- Wiring
DS-K4H250S & DS-K4H258S
Please connect as the following picture:
Magnetic lock LED status:
Normal(Close Door)
Normal(Open Door)
Abnormal
DS-K4H250D & DS-K4H450D & DS-K4H258D
Please connect as the following picture:
Magnetic lock LED status:
Normal(Close Door)
Normal(Open Door)
Abnormal
