DS-K4H250/450/258 series magnetic lock

connect to DS-K2600 series Access Controller

Version:

v1.0

Date:

01/11/2018

Product:

Access Control Device

Page:

6 of 9

Step 5:

Enter Status Monitor  Door Status interface, open the door, check door status on iVMS-4200 Client

and the magnetic lock LED status;

Magnetic Lock

LED status

Door Status

Alarm Event

Part 3: Lock+/Lock- & NO/COM Wiring

Step 1:

DS-K4H250S

Please connect as the following picture:

Magnetic lock LED status:

Normal(Close Door)

Normal(Open Door)

Abnormal
