1. Brief Description
The Handheld Thermal Camera is a camera with both
optical images and thermal images. The built-in
high-sensitivity IR detector and high-performance sensor
detects the temperature change and measure the
real-time temperature.
You can view live view, capture snapshots, record videos
via HIKMICRO Viewer on your phone. You can also analyze
pictures offline, generate and share a report via the app.
Scan the QR codes on the cover to download the app.
You can download HIKMICRO Analyzer
(https://www.hikmicrotech.com/en/industrial-products/hi
kmicro-analyzer-software.html) to analyze pictures offline
professionally, and generate a custom format report on
your PC.
HIKMICRO Viewer Android
HIKMICRO Viewer iOS
2. Component & Interface (Page 1)
The appearances of different models may vary
(Appearance I & Appearance II). Please take the actual
product for reference.
No.
Component
Function
1
Charging
Indicator
 Solid Red: Charging.
 Solid Green: Fully charged.
2
Touch Screen
 Show the live view
interface.
 Touch-screen operation.
3
Microphone
Input audio information.
4
Loud Speaker
Play voice note, voice alarm and
video voice.
Navigation
Button
Menu Mode:
 Press , , , and  to
select parameters.
 Press OK to confirm.
5
Non-Menu Mode:
 Press  to turn on/off the
LED light supplement.
 Press  to start digital
zoom.
6
Power Button
Hold: Power on/off.
7
Laser Button
Hold the button to turn on laser,
and release the button to turn
off laser.
8
Shutter Button
Cover the lens to perform the
correction.
9
Back Button
Exit the menu or return to
previous menu.
10
Focus Ring
Adjust lens to make the image
clear (only supported by certain
models).
11
Thermal Lens
View the thermal image.
12
Tripod Mount
Mount the tripod.
13
Trigger
 Menu Mode: Pull the
trigger to return to the live
view interface.
 Non-Menu Mode: Pull the
trigger to capture. Hold the
trigger to record videos.
14
Battery
Provide power for the device.
15
Lens Cover
Cover the lens.
16
LED Light
Increase ambient brightness in
dark environment.
17
Laser
Transmitter
Indicate the direction.
18
Optical Lens
View the optical image.
19
Cable Interface
Charge the device or export files
with supplied cable.
20
Micro SD Card
Slot
For holding the Micro SD card.
Note: The warning sign is inside the lens cover.
3. Charge Device
Please charge the device when the battery is low. For the
first charge, turn on the device and charge it for more
than 8 hours. The device clock may roll back to the default
time, if the device is not fully charged.
Note:
 The built-in cell battery that powers the real time
clock (RTC) of the device may drain during longtime
transportation or storage. It is recommended to
recharge the RTC battery for the wellfunctioning of
the device clock.
 To fully charge the RTC battery, the following
requirements should be met:
a) The rechargeable lithium batteries should be
installed on the device.
b) The device should keep working for more than 8
hours before shutting down.
3.1 Charge Device via Cable Interface
Steps
1. Lift the cover of interface.
2. Plug in the cable, and charge the device.
3.2 Charge Device via Charging Base
Steps:
1. Hold the device, and press both battery lock catches
of the device.
Battery Lock Catch
Battery Base
2. Hold the lock catches, and draw the battery base to
remove the battery.
