Thermal Image Scope User Manual
4
Figure 1-3 Interfaces of Thermal Telescope
Table 1-2 Interface Description
No.
Component
Function
1
Lens Cover
Protect the lens.
2
Focus Ring
Adjust the focal length.
3
Data Exchange
Interface
Connect with the output cable.
4
Fixing Ring
Fix the eyepiece.
5
Battery
Compartment
Install the battery in it.
6
Bolt
Loosen the bolt to install the batteries.
7
Diopter
Adjustment Ring
Adjust the dioptric correction.
8
Eyepiece
View the target.
9
Knob
Secure the device to the rail.
