3.8 Flat Field Correction
This function can correct non-uniformity of display.
Steps
1. Hold to go to the menu.
2. Select and press to switch FFC mode.
– Manual: Hold in live view to trigger calibration.
– Auto: The device performs FFC automatically according to the set schedule when switching
on the camera.
– External: Cover the lens cover, then hold in live view to trigger calibration.
3. Hold to save the settings and exit.
3.9 Set Picture in Picture Mode
Steps
1. In the view mode, hold to show the menu.
2. Select and enter PIP mode. The details show in the upper center.
● When reticle is enabled, the PIP view is the detail of reticle.
● When reticle is not enabled, the PIP view is the detail of central part.
● Figure 3-4 Set Picture in Picture Mode
3. Hold to exit.
