4
English
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package
contains the accessories listed in the below.
(1) Chuck wrench (Spec. only for keyed chuck) ................1
(2) Side handle ..................................................................1
(3) Depth gauge ................................................................1
Standard accessories are subject to change without notice.
APPLICATIONS
Boring holes in metal, wood and plastic.
SPECIFICATIONS
Voltage*
(110 V, 120 V, 220 V, 230 V, 240 V)
Power input 860 W*
Speed range 1 2
No load speed 0 – 1100 /min 0 – 3000 /min
Capacity
Steel 13 mm 8 mm
Wood 40 mm 25 mm
Weight 2.9 kg
* Be sure to check the nameplate on product as it is subject
to change by areas.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
MOUNTING AND OPERATION
Action Figure Page
Insulated gripping surface 1 23
Fixing and removing side handle
223
Using depth gauge 3 23
Mounting and dismounting of
the bit
423
Selecting rotation direction 5 24
Switch operation
624
Locking-on the switch
724
Releasing the switch
824
Change rotation speed
925
Selecting accessories ― 26
Selecting the appropriate drill bit
○ When boring metal or plastic
Use an ordinary metalworking drill bit.
○ When boring wood
Use ordinary woodworking drill bit.
However, when drilling 6.5 mm or smaller holes, use a
metalworking drill bit.
MAINTENANCE AND INSPECTION
1. Inspecting the drill bits
Since use of an abraded drill bits will cause motor
malfunctioning and degraded effi ciency, replace the drill
bits with a new one or resharpening without delay when
abrasion is noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool. Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
4. Inspecting the carbon brushes
For your continued safety and electrical shock protection,
carbon brush inspection and replacement on this tool
should ONLY be performed by a HiKOKI Authorized
Service Center.
5. Replacing supply cord
If the replacement of the supply cord is necessary, it
has to be done by HiKOKI Authorized Service Center to
avoid a safety hazard.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
