CBF&CB SERIES USER MANUAL
26
4.2 Remove receiving card
4.2.1 Pull out the button terminal and remove
the receiving card fixing screw
4.2.2 Take out receiving card
4.3 Remove adapter plate (Also called HUB).
4.3.1 Remove the three adapters plate retaining
screws
4.3.2 Remove adapter plate (HUB)
