HIKVISION DS-1100KI Technical Manual

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
Functions & Performances
 Realize video switching for the matrix system and multi-channel
decoder;
 PTZ control of the connected camera;
 3-axis joystick for PTZ control;
 Shutter button for playback control;
 Ergonomic design with 800×480 LCD touch panel;
 Live view and playback of video on the touch screen at
1080p/720p/4CIF/DCIF/2CIF/CIF resolution;
 User-defined camera/monitor group for switching video outputs;
 Support cycle switching/control of multiple cameras;
 Multi-window division display modes selectable;
 User-defined macro command operation;
 Settings and callup of preset, patrol and pattern;
 Playback control of record files directly by keyboard: play fast, play
slow, skip forward, skip backward, reverse, pause, stop, etc.;
 Video capture and recording to local U-flash disk;
 Upgrade by USB connection and import & export of configuration files;
 Voice talking with the device;
 Support DHCP, SADP, protocol, etc.;
 Compatible with HIKVISION DVR/DVS, multi-channel video decoder,
matrix, IP camera, IP dome, PC-DVR, etc.;
 Support 15 operators, and each user is allowed to operate 256 devices.

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
