HIKVISION DS-1100KI Technical Manual

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
Specifications
Model DS-1100KI
Control Mode IP-based
TFT LCD Panel
7” TFT LCD monitor with touch panel
Resolution: 800×480
Joystick 3-axis joystick
Audio
Input/Output
Line In
1-ch, 3.5mm connector (2.0Vp-p, 1kΩ）
Audio Out
1-ch, 3.5mm connector (Linear, 600Ω)
External
Interface
Network
Interface
1 RJ45 10M/100M/1000M adaptive
Ethernet interface
RS-232 Interface 1 RS-232 interface
RS-485 Interface 1 RS-485 interface
USB Interface
1, USB2.0 (for
data storage and device
upgrade)
General
Power Supply DC 12V
Power
Consumption
≤15W
Working
Temperature
-10℃~+55℃
Working Humidity
10%～90%
Size 110mm (H)×193mm (W) ×435mm (D)
Weight 2Kg

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
