2.4 Wall Mounting with a Bracket
You have to purchase the bracket separately if this mounting method
is selected.
1. Install the bracket to the wall.
2. Install the mounting base to the bracket.
3. Screw the three supplied screws half-deep to the mounting base.
Install the Bracket Figure 2-12
4. Connect the corresponding power cable, network cable, audio
and alarm cables.
5. Align the screw holes to the inserted screws, hook the camera
body to the screws, and route the camera body to secure the
camera with the screws.
6. Screw the half-deep screws into the mounting base totally.
