Network Dome Camera·Quick Start Guide
17
17
4). Use a flat-bladed screwdriver to loosen the tilt adjusting
screw and adjust the tilting position from 0° to 60°. Tighten
the screw when finishing adjusting.
Tilt Adjusting
Screw
Adjust Tilting Position (1) Figure 2-7
Tilt: 0°- 60°
Adjust Tilting Position (2) Figure 2-8
