HIKVISION DS-2CD864-EI3 Installation Manual

Installation Manual of Network Camera
75
Figure 3-108 Disassemble the Camera
3. Fix the adapter plate to the ceiling with the supplied expansion screws.
Adapter Plate
Side Outlet
Figure 3-109 Fix the Adapter Plate
If the supplied drill template is type II drill template, you can skip step 3 and go straight to step 4.
4. Fix the dome drive with the supplied PM4x8 screws.
