HIKVISION DS-2CE10DF0T-F

 To avoid heat accumulation, good ventilation is
required for the operating environment.
 Keep the camera away from liquid while in use for
non-water-proof device.
 While in delivery, the camera shall be packed in its
original packing, or packing of the same texture.
Mark Description
Table 0-1 Mark Description
Mark
Description
DC Voltage
1 Introduction
1.1 Product Features
The main features are as follows:
 High performance CMOS sensor
 OSD menu with configurable parameters
 24-hour color image
 Smart light
 3-axis adjustment
1.2 Overview
1.2.1 Overview of Type I Camera
Power Cord
Video Cable
Switch Button
Bracket
Main Body
Lens
Figure 1-1 Overview of Type I Camera
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS
1.2.2 Overview of Type II Camera
Power Cord
Video Cable
Switch Button
Bracket
Main Body
Lens
Figure 1-2 Overview of Type II Camera
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
1.2.3 Overview of Type III Camera
DC12VIN
Video Cable
Switch Button
Power Cord
Base
Gang Box
Enclosure
Main Body
