HIKVISION DS-2CV2021G2-IDW Quick Start Guide

Network Bullet Camera·Quick Start Guide
17
 The junction box is not included in the package. You need to
prepare one for this mounting type
Steps:
1. Paste the drill template (supplied) to the desired mounting position
on the wall.
2. Drill the screw holes and the cable hole (optional) in the wall
according to the drill template.
Figure 2-5 Drill Template
3. Take apart the junction box, and align the screw holes of the bullet
camera with those on the junction box's cover.
4. Fix the camera on the junction box's cover with screws.
Figure 2-6 Fix the Camera on Junction Box's Cover
