HIKVISION DS-2CV2021G2-IDW Quick Start Guide

Network Bullet Camera·Quick Start Guide
16
4. Connect the cables and power on the camera to view live view
image.
5. Adjust the angle.
The adjusting range of the panning is from 0° to 360°, range of the
tilting is from 0° to 90° and range of the rotation is 0° to 360°. The
adjusting range of the Wi-Fi antenna is from 0° to 270°.
P: 0° to 360°
270
°
T: 0° to 90°
R: 0° to 360°
Wi-Fi Antenna:
0° to 270°
Figure 2-4 Angle Adjustment
6. (Optional) Install the waterproof jacket. Refer to 2.4 Waterproof
Measures for details.
Wall Mounting with Junction Box
Before you start:
 Both wall mounting and ceiling mounting are suitable for the bullet
camera. Wall mounting will be taken as an example in this section.
And you can take steps of wall mounting as a reference for ceiling
mounting.
