Steps:
(1) Click Add to add an IP.
(2) Input the IP Adreess.
Figure 6-54 Add an IP
(3) Click OK to finish adding.
Modify an IP Address
Steps:
(1) Left-click an IP address from filter list and click Modify.
(2) Modify the IP address in the text filed.
Figure 6-55 Modify an IP
(3) Click OK to finish modifying.
Delete an IP Address
Left-click an IP address from filter list and click Delete.
Delete all IP Addresses
Click Clear to delete all the IP addresses.
5. Click to save the settings.
Configure Security Service Settings
Steps:
1. Enter the Security Service interface:
Configuration> System > Security > Security Service
2. Check the checkbox to enable the Illegal Login Lock function.
Illegal Login Lock: Enabling illegal login lock function is to automatically lock the device IP
after the admin user performing 7 failed password attempts (5 attempts for the
user/operator).
3. Click to save the settings.
