(5) Click to save the settings.
The time of each period cannot be overlapped. Up to 8 periods can be configured for each
day.
5. Set the Alarm Actions for Motion Detection.
Click tab to enter the Linkage Method interface.
You can specify the linkage method when an event occurs. The following contents are about
how to configure the different types of linkage method.
Figure 5-14 Linkage Method
Check the checkbox to select the linkage method. Notify Surveillance Center, Send
Email, Upload to FTP/Memory/NAS, Trigger Alarm Output and Trigger Recording are
selectable.
Notify Surveillance Center
Send an exception or alarm signal to remote management software when an event
occurs.
Send Email
Send an email with alarm information to a user or users when an event occurs.
To send the Email when an event occurs, you need to refer to Section Configuring Email
Settings to set the Email parameters.
Upload to FTP/Memory/NAS
