HIKVISION DS-2DF1-512 User Manual

Hikvision Technical Manual
©2006 – 2011 by HIKVISION. All rights reserved.
4
Application
It can be widely applied to places requiring wide-area monitoring display, such as rivers, forests, highways, railways,
airports, ports, sentries, squares, parks, scenic sites, streets, stations, large venues, outside of residential areas, etc
Specifications
Model
Parameter
DS-2DF1-512(Outdoor)
DS-2DF1-502(Indoor)
DS-2DF1-532(In-ceiling)
DS-2DF1-514(Outdoor)
DS-2DF1-504(Indoor)
DS-2DF1-534(In-ceiling)
DS-2DF1-516(Outdoor)
DS-2DF1-506(Indoor)
DS-2DF1-536(In-ceiling)
DS-2DF1-518(Outdoor)
DS-2DF1-508(Indoor)
DS-2DF1-538(In-ceiling)
5 Inch Network High Speed Dome
Camera
Image Sensor
1/4’’ Sony Super HAD CCD
Effective Pixel
PAL:752(H)×582(V)
NTSC:768(H)×494(V)
Horizontal
Resolution
480TVL
Color: 540 TVL
B/W: 570 TVL
Signal System
PAL /NTSC
Min.
Illumination
0.1Lux/F1.6
Color: 0.2Lux/F1.6
B/W:0.02Lux/F1.6
Color: 0.2Lux/F1.4
B/W:0.02Lux/F1.4
Color: 0.2Lux/F1.6
B/W:0.02Lux/F1.6
White Balance
Auto / Manual / ATW / Indoor / Outdoor
AGC
Auto / Manual
S / N Ratio
≥ 50dB
BLC
On / Off
Shutter Time
PAL:1/50-1/10,000s
NTSC:1/60-1/10,000s
PAL:1-1/10,000s
NTSC:1-1/10,000s
Day & Night
Electronic
IR Cut Filter
Digital Zoom
--
16x
Privacy Mask
24 privacy masks programmable;
a maximum of 24 zones can be masked simultaneously on the same video screen
Focus Model
Auto / Semiautomatic / Manual
Lens
Focal Length
3.9-85.8mm, 22X
3.84-88.4 mm, 23X
3.5-105mm, 30X
3.4-122.4mm, 36X
Zoom Speed
Approx.4.3s(Optical
Wide-Tele)
Approx.5.1s(Optical
Wide-Tele)
Approx.5.4s(Optical Wide-Tele)
Angle of View
58.0-2.22degree
(Wide-Tele)
52.2-2.36degree(Wide-Tele)
56.4-2.0degree(Wide-Tele)
57.8-1.7degree
(Wide-Tele)
Min. Working
Distance
10-1,000mm(Wide-Tele)
10-1,200mm(Wide-Tele)
10-1,000mm(Wide-Tele)
Aperture Range
F1.6 - F3.7
F1.6 - F4.5
F1.4 - F3.7
F1.6 - F4.5
Pan and
Tilt
Pan Range
360°endless
Pan Speed
Pan Manual Speed: 0.1° -400°/s,

HIKVISION DS-2DF1-512 Specifications

General

Brand	HIKVISION
Model	DS-2DF1-512
Category	Security Camera
Language	English
