HIKVISION DS-2TD1217-6/PA User Manual

Thermal & Optical Bi-spectrum Network Camera User Manual
42
Player means the VCA info can be displayed by the dedicated player provided by the
manufacturer.
Video
Video means the VCA info can be displayed by any general video player.
9.1.10 Audio Settings
It is a function to set audio parameters such as audio encoding, environment noise filtering.
Go to the audio settings page: Configuration → Video/Audio → Audio.
Note
Only certain camera models support the function.
Audio Encoding
Select the audio encoding compression of the audio.
Audio Input
Note
● Connect the audio input device as required.
● The audio input display varies with the device models.
LineIn
Set Audio Input to LineIn when the device connects to the
audio input device with the high output power, such as MP3,
synthesizer or active pickup.
MicIn
Set Audio Input to MicIn when the device connects to the
audio input device with the low output power, such as
microphone or passive pickup.
Environmental Noise Filter
Set it as OFF or ON. When the function is enabled, the noise in the environment can be filtered to
some extent.
9.1.11 Two-way Audio
It is used to realize the two-way audio function between the monitoring center and the target in

HIKVISION DS-2TD1217-6/PA Specifications

General

Model	DS-2TD1217-6/PA
Category	Security Camera
Thermal Module: Image Sensor	Uncooled VOx Microbolometer
Resolution	160 × 120
Pixel Interval	17μm
Lens (Focal Length)	6.8mm
Aperture	F1.0
Visible Light Module: Image Sensor	1/2.7" Progressive Scan CMOS
Protection Level/IP Rating	IP67
Response Waveband	8μm ~ 14μm
Thermal Sensitivity/NETD	≤ 50mK
Digital Zoom	8x
Visible Light Module: Min. Illumination	0.01 Lux @ (F1.2, AGC ON)
Video Resolution	1920 x 1080
Frame Rate	25 fps
Image Settings	Brightness, Contrast, Saturation
Temperature Measurement Range	-20 °C to 150 °C
Temperature Measurement Accuracy	±2°C or ±2%
Video Output	1 Vp-p composite output (75 Ω/BNC)
Alarm Input	1
Alarm Output	1
RS-485	1-channel
Power Supply	DC12V ±25%
Working Temperature/Humidity	Humidity: 95% or less
Focus	Fixed
