Network Mini Dome Camera·Quick Start Guide
13
Cable Description
No.
Description
1
RJ45 Network Cable
2
M12 Aviation Plug
3
Video Out (BNC)
4
Power Supply and
Audio Out Cable
Black: power negative
Red: power positive
White and Brown: audio out
5
Power Supply Cable
6
Audio Out (Line Out) Cable
The relation between RJ45 wire and M12 wire is shown in the
following figure and table.
1 2
3
4
1
8
M12 Aviation Plug RJ45 Network Interface
Figure 1-3 RJ45 Interface and M12 Aviation Plug
