DS-6700HUHI-K Series Encoder Quick Start Guide
8
The rear panel of DS-6704/6716HUHI-K provides 4/16 video input interfaces.
Table 1. 2 Interface Description
Description
1
VIDEO IN
2
AUDIO IN, RCA Connector
3
AUDIO OUT, RCA Connector
4
RS-232 Serial Interface
5
LAN Network Interface
6
RS-485 Serial Interface
7
12 VDC Power Input
8
Alarm In/Out
9
Power Switch
10
GND
