HIKVISION DS-7216HQHI-F1/N Quick Start Guide

Digital Video Recorder Quick Start Guide
29
Step 3 Click OK to log in.

Clear-text password is supported. Click the icon and you can see the clear text of the
password. Click the icon again and the content of the password restores invisible.

In the Login interface, for the admin, if you have entered the wrong password for 7 times,
the account will be locked for 60 seconds. For the operator, if you have entered the wrong
password for 5 times, the account will be locked for 60 seconds.
Figure 3-11 User Account Protection for the Admin
Figure 3-12 User Account Protection for the Operator
Step 4 (Optional) If you forget the password, click Forget Password to pop up the Import GUID
interface.
Figure 3-13 Import GUID
1) Select the GUID file from the USB flash disk and click Import button to pop up the
Reset Password interface

HIKVISION DS-7216HQHI-F1/N Specifications

General

Video input channels	16 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Power consumption (typical)	30 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Analog signal format system	NTSC, PAL
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
