HIKVISION DS-7316HGHI-SH User Manual

User Manual of Digital Video Recorder
15
1.1 Front Panels
Figure 1. 1 Front Panel of DS-7100HGHI-SH
Table 1. 1 Description of Front Panel
No.
Icon
Description
1
Indicator turns red when DVR is powered up.
2
Indicator lights in red when data is being read from or written to HDD.
3
Indicator blinks blue when network connection is functioning properly.
Figure 1. 2 Front Panel of DS-7204/7208HGHI-SH
Figure 1. 3 Front Panel of DS-7216HGHI-SH
Table 1. 2 Description of Front Panel
No.
Name
Function Description
1
POWER
Power indicator turns yellow when the power switch on the real
panel is turned on.
STATUS
Status indicator blinks red when data is being read from or written to
HDD.

HIKVISION DS-7316HGHI-SH Specifications

General

Brand	HIKVISION
Model	DS-7316HGHI-SH
Category	DVR
Language	English
