DS-7600 Series NVR User Manual
14
IR Remote Control Operations
The NVR may also be controlled with the included IR remote control, shown in Figure 6.
Figure 6, IR Remote Control
Enable/Disable Remote Control
corresponding channel in Live V
Input numbers and characters in Edit mode
Switch between different channels in All
Delete characters before cursor
Check the checkbox and select the ON/OFF switch
Start/stop record clipping in playback
Adjust focus in the PTZ Control menu
It is also used to switch between input methods (upper and lowercase alphabet, symbols and numeric input)
Enter the Manual Record setting menu
In PTZ control settings, press the button and then call a PTZ preset by pressing
It is also used to turn audio on/off in the Playback mode
The button is used to enter the All
It is also used to auto scan in
Zoom in the PTZ camera in the PTZ Control setting
Switch between main and spot output
In PTZ Control mode, it can zoom out the image
return to the Main menu (after successful login)
PTZ Control mode, MENU/WIPER button will start wiper (if applicable)
Switch between single screen and multi
In PTZ Control mode, adjust
focus in conjunction with the A/FOCUS+ button
DIRECTION buttons navigate between different fields and menu items
In Playback mode, Up and Down button speeds up and slows down recorded video. Left and Right button will
In Live View mode, cycle through channels
In PTZ control mode, controls movement of the PTZ camera
Confirms selection in any menu mode
In Playback mode, plays or pauses the video
frame Playback mode, advances video a single frame
switch mode, stops/starts auto switch
In PTZ Control mode, adjust
the device in Live View mode
Select all items list in a list field
In PTZ Control mode, turn on/off PTZ light (if applicable)
between play and reverse play
In synchronous playback mode, switch
