HIKVISION DS-7600 Series

DS-7600 Series NVR User Manual
41
Figure 46, PTZ Control Mode
3. Control the PTZ by using PTZ control buttons. Pan and tilt PTZ by clicking on the directional buttons. Zoom in and out using the
Zoom In/Out buttons and recall presets, patrols and patterns by clicking the corresponding icons.
Below are descriptions of the PTZ control icons:
Direction buttons and the auto-cycle button
Zoom+/Zoom-
Focus+/Focus-
Iris+/Iris-
The speed of the PTZ movement
Light On/Off
Wiper On/Off
3D-Zoom
Image Centralization
Menu
4. Click to return to Live Feed mode.
NOTE: PTZ parameters for the camera must be set correctly before the PTZ can be controlled.
Digital Zoom Mode
Enable digital zoom on the selected channel. Once enabled, the regular feed will be shown in the lower right corner while the zoomed in
view will be shown on the full screen. The zoomed in region may be changed by moving the red rectangle in the regular feed window, as
shown in Figure 47. Right click to go back to Live Feed mode.
